GSM天线特性
|
NO |
项目(Item) |
特性(Specifications) |
PostEnvironmental Tolerance (试验后允许附加误差) |
|
1 |
GSM接收频率范围（MHz） Range of Receiving Frequency |
824~960MHz 1800MHz 1900MHz |
±2.5 |
|
2 |
WIFI接收频率范围（MHz） Range of Receiving Frequency |
2.4~2.4835GHz |
±3.0 |
|
3 |
带宽Band Width(MHz) (Retum Loss≤-10dB) |
≥10 |
±0.5 |
|
4 |
驻波比V.S.W.R(in Center Frequency) |
≤1.5 |
±0.5 |
|
5 |
增益Gain (Zenith)(dBi typ) (with 70mmSquare GND plane) |
0 |
±0 |
|
6 |
特性阻抗mpedance(Ω) | 50 |
4G+5G特性
|
NO |
项目(Item) |
特性(Specifications) |
|
1 |
5.8G频率范围 |
5725~5850MHZ |
|
2 |
4G频率范围 |
1880~2635MHz |
|
3 |
驻波比 |
≤2.0 |
